Hydr-App Agri Gear Boxes
Description
P.T.O. gearboxes provide the connection for a hydraulic pump to a low speed tractor power take off. The standard P.T.O. speed, 540 rpm, is increased by the gearbox to the optimal speed conditions for the pump. Different input speeds are accepted but the output speed should not exceed 3000 rpm.
Minimum and maximum temperatures should not exceed -20C and +80C.
Torque data listed is for continuous duty and can be increased by 25% intermittently.
The oil level must be maintained to the proper level and should be changed after the first 35/50 hours use and thereafter at least every 12 months.
Specifications
|
Model |
Ratio |
Description |
Output Torq. Nm |
|
ML32-1-1/2.5 |
2.5:1 |
Group 2, 1 3/8” 6T spline input - male |
58 |
|
ML32-1-1/3.5 |
3.5:1 |
Group 2, 1 3/8” 6T spline input - male |
58 |
|
ML32-2-1/2.5 |
2.5:1 |
Group 2, 1 3/8” 6T spline input - female |
58 |
|
ML32-2-1/3.5 |
3.5:1 |
Group 2, 1 3/8” 6T spline input - female |
58 |
|
ML32-3-1/3 |
3:1 |
Group 2, 1 3/8” 6T spline input - female quick release |
58 |
|
|
|
|
|
|
ML52-1-1/2 |
2:1 |
Group 2/3, 1 3/8” 6T spline input - male |
130 |
|
ML52-1-1/3 |
3:1 |
Group 2/3, 1 3/8” 6T spline input - male |
130 |
|
ML52-1-1/3.4 |
3.4:1 |
Group 2/3, 1 3/8” 6T spline input - male |
130 |
|
ML52-2-1/2 |
2:1 |
Group 2/3, 1 3/8” 6T spline input - female |
130 |
|
ML52-2-1/2.6 |
2.6:1 |
Group 2/3, 1 3/8” 6T spline input - female |
130 |
|
ML52-2-1/3.4 |
3.4:1 |
Group 2/3, 1 3/8” 6T spline input - female |
130 |
|
ML52/B-8-1/3.4 |
3.4:1 |
Group 2/3, 1 3/8” 6T spline input - female 1 3/8” 6T spline output - male |
130 |
- NOTE: Spline sleeves listed below are required in addition to gearbox and pump combination.
|
Configuration Options Click here to view spline sleeves |
|
| BF2 | ML32 Spline sleeve - Group 2, 1 in 8 internal taper to 14T |
| BF3/2 | ML52 Spline sleeve - Group 2, 1 in 8 internal taper to 18T |
| BF3 | ML52 Spline sleeve - Group 3, 1 in 8 internal taper to 18T |
Downloads
| Code | Product Name | Price | Stock Availability | Quantity | Enquire |
|---|---|---|---|---|---|
|
14050011
|
14050011
HYDR-APP FLANGE B600 SAE "B"
|
$313.40
|
Call
|
|
|
|
34207100
|
34207100
HYDR-APP PVC WASHER ML32/52
|
$5.30
|
Call
|
|
|
|
43000300
|
43000300
HYDR-APP PINS
|
$9.30
|
Call
|
|
|
|
43201000
|
43201000
HYDR-APP KEY ML32
|
$11.95
|
Call
|
|
|
|
43201100
|
43201100
HYDR-APP KEY ML52
|
$11.95
|
Call
|
|
|
|
49100100
|
49100100
HYDR-APP BREATHER IE/IM CLUTCH
|
$20.85
|
Call
|
|
|
|
49100500
|
49100500
HYDR-APP SIGHT GLASS ML32/52
|
$22.60
|
Call
|
|
|
|
49100700
|
49100700
HYDR-APP PLUG ML32/52
|
$13.30
|
Call
|
|
|
|
49101700
|
49101700
HYDR-APP BREATHER ML52
|
$31.90
|
Call
|
|
|
|
49118700
|
49118700
HYDR-APP SIGHT GLASS ML32/52
|
$22.60
|
Call
|
|
|
|
90200003
|
90200003
HYDR-APP ML52 SHAFT FEMALE
|
$355.95
|
Call
|
|
|
|
ML32-1-1/2.5
|
ML32-1-1/2.5
HYDR-APP PTO GEARBOX MALE GR2
|
$572.40
|
Call
|
|
|
|
ML32-1-1/3.5
|
ML32-1-1/3.5
HYDR-APP PTO GEARBOX MALE GR 2
|
$572.40
|
Call
|
|
|
|
ML32-2-1/2.5
|
ML32-2-1/2.5
HYDR-APP PTO GEARBOX FEMALE GR2
|
$572.40
|
Call
|
|
|
|
ML32-2-1/3.5
|
ML32-2-1/3.5
HYDR-APP PTO GEARBOX FEMALE GR 2
|
$572.40
|
Call
|
|
|
|
ML32-3-1/3
|
ML32-3-1/3
HYDR-APP PTO GEARBOX FEMALE GR2 QUICK RELEASE
|
$806.15
|
Call
|
|
|
|
ML52-1-1/2
|
ML52-1-1/2
HYDR-APP PTO GEARBOX MALE GR 3
|
$1,021.35
|
Call
|
|
|
|
ML52-1-1/3
|
ML52-1-1/3
HYDR-APP PTO GEARBOX MALE 1:3
|
$1,021.35
|
Call
|
|
|
|
ML52-1-1/3.4
|
ML52-1-1/3.4
HYDR-APP PTO GEARBOX MALE GR 3
|
$1,021.35
|
Call
|
|
|
|
ML52-2-1/2
|
ML52-2-1/2
HYDR-APP PTO GEARBOX FEMALE GR 3
|
$1,021.35
|
Call
|
|
|
|
ML52-2-1/2.6
|
ML52-2-1/2.6
HYDR-APP PTO GEARBOX FEMALE GR 3
|
$1,021.35
|
Call
|
|
|
|
ML52-2-1/3.4
|
ML52-2-1/3.4
HYDR-APP PTO GEARBOX FEMALE GR 3
|
$1,021.35
|
Call
|
|
|
|
ML52-3-1/3
|
ML52-3-1/3
HYDR-APP PTO GEARBOX FEM/MALE GR 3
|
$1,301.50
|
Call
|
|
|
|
ML52/B-8-1/3.4
|
ML52/B-8-1/3.4
HYDR-APP PTO GEARBOX FEM/MALE GR 3
|
$1,086.40
|
Call
|
|
|
