Eaton / Vickers Cetop Modules
Cetop 3 Systemstak Modules
Max. pressure - 315 bar
Max. flow capacity - 60 lpm
|
DGMC Series - Relief Valve |
|
|
694419 |
Relief on P port to tank, 10-200 bar |
|
869641 |
Relief on P port to tank, 50-315 bar |
|
869627 |
A & B port cross over relief, 3-100 bar |
|
871708 |
A & B port cross over relief, 50-315 bar |
|
871702 |
A & B port venting to tank, 50-315 bar |
|
DGMX2 - Pressure Reducing/Relieving Valve |
|
|
870021 |
Pressure reducer on P port, 3-30 bar |
|
870036 |
Pressure reducer on P port, 3.5-70 bar |
|
870037 |
Pressure reducer on P port, 10-140 bar |
|
870038 |
Pressure reducer on P port, 20-250 bar |
|
DGMFN - Throttle & Check Valve |
|
|
870043 |
Throttle on P port, meter in. |
|
694413 |
Throttle & check A & B port, meter in, fine control |
|
694414 |
Throttle & check A & B port, meter in, standard control |
|
694411 |
Throttle & check A & B port, meter out, fine control |
|
694412 |
Throttle & check A & B port, meter out, standard control |
|
DGMPC - Pilot Check Valve |
||
|
694400 |
Dual pilot check A & B port |
|
|
870024 |
Pilot check in A port, pilot from B |
|
|
464125 |
Valve & one 40mm stack - M5 x 70mm |
|
466840 |
Valve & two 40mm stacks - M5 x 110mm |
|
466844 |
Valve & three 40mm stacks - M5 x 150mm |
CETOP 5 Systemstak Modules
Max. pressure - 315 bar
Max. flow capacity - 120 lpm
|
DGMC Series - Relief Valve |
|
|
867315 |
Relief on P port to tank, 4-315 bar |
|
867323 |
A & B port cross over relief, 4-315 bar |
|
02-101918 |
A & B port venting to tank, 4-200 bar |
|
DGMX2 - Pressure Reducing/Relieving Valve |
|
|
868864 |
Pressure reducer on P port, 8.5-315 bar |
|
868656 |
Pressure reducer on A port, 8.5-315 bar |
|
DGMFN - Throttle & Check Valve |
|
|
867335 |
Throttle & check A & B port, meter in, standard control |
|
867332 |
Throttle & check A & B port, meter out, standard control |
|
DGMPC - Pilot Check Valve |
|
|
867364 |
Dual pilot check A & B port |
|
DGMR – Counterbalance Valve |
|
|
02-145385 |
Single, Throttle & check A & B port, meter in, standard control |
|
02-145387 |
Dual, Throttle & check A & B port, meter out, standard control |
|
534576 |
Valve & one 50mm stack - M6 x 90mm |
|
638878 |
Valve & two 50mm stacks - M6 x 140mm |
Downloads
| Code | Product Name | Price | Stock Availability | Quantity | Enquire |
|---|---|---|---|---|---|
|
02-101918
|
02-101918
EATON MODULE DGMC2-5-ATFW-BTFW-S-30
|
$1,023.20
|
Call
|
|
|
|
02-108132
|
02-108132
EATON MODULE DGMC-3-PT-AW-41
|
$429.50
|
Call
|
|
|
|
02-157280
|
02-157280
EATON MODULE DGMC2-3-ABAW-BAAW-41
|
$695.70
|
Call
|
|
|
|
02-157586
|
02-157586
EATON MODULE DGMC-3-PT-GK-41
|
$789.75
|
Call
|
|
|
|
694400
|
694400
EATON MODULE DGMPC-3-ABK-BAK-41
|
$456.65
|
In Stock
|
|
|
|
694411
|
694411
EATON MODULE DGMFN-3Y-A1W-B1W-41
|
$421.55
|
Call
|
|
|
|
694412
|
694412
EATON MODULE DGMFN-3Y-A2W-B2W-41
|
$421.55
|
Call
|
|
|
|
694413
|
694413
EATON MODULE DGMFN-3X-A1W-B1W-41
|
$420.38
|
Call
|
|
|
|
694414
|
694414
EATON MODULE DGMFN-3X-A2W-B2W-41
|
$421.55
|
Call
|
|
|
|
694415
|
694415
EATON MODULE DGMDC-3-YPK-41
|
$228.95
|
Call
|
|
|
|
694419
|
694419
EATON MODULE DGMC-3-PT-CW-41
|
$509.90
|
Call
|
|
|
|
867315
|
867315
EATON MODULE DGMC-5-PT-GW-S-30
|
$613.00
|
Call
|
|
|
|
867323
|
867323
EATON MODULE DGMC2-5-ABGW-BAGW-30
|
$957.50
|
Call
|
|
|
|
867332
|
867332
EATON MODULE DGMFN-5Y-A2W-B2W-30
|
$508.77
|
Call
|
|
|
|
867335
|
867335
EATON MODULE DGMFN-5X-A2W-B2W-30
|
$509.90
|
Call
|
|
|
|
867340
|
867340
EATON MODULE DGMPC-5-BAK-30
|
$509.90
|
Call
|
|
|
|
867364
|
867364
EATON MODULE DGMPC-5-ABK-BAK-30
|
$632.25
|
In Stock
|
|
|
|
869627
|
869627
EATON MODULE DGMC2-3-ABBW-BABW-41
|
$685.55
|
Call
|
|
|
|
869641
|
869641
EATON MODULE DGMC-3-PT-GW-41
|
$509.90
|
In Stock
|
|
|
|
870021
|
870021
EATON MODULE DGMX2-3-PP-AW-B-40
|
$598.25
|
Call
|
|
|
|
870023
|
870023
EATON MODULE DGMPC-3-BAK-41
|
$421.55
|
Call
|
|
|
|
870024
|
870024
EATON MODULE DGMPC-3-ABK-41
|
$421.55
|
Call
|
|
|
|
870037
|
870037
EATON MODULE DGMX2-3-PP-CW-40
|
$598.25
|
Call
|
|
|
|
870038
|
870038
EATON MODULE DGMX2-3-PP-FW-B-40
|
$598.25
|
Call
|
|
|
|
870043
|
870043
EATON MODULE DGMFN-3Z-P2W-41
|
$421.55
|
Call
|
|
|
|
870267
|
870267
EATON MODULE DGMX2-3-PB-CW-B-40
|
$598.25
|
Call
|
|
|
|
871702
|
871702
EATON MODULE DGMC2-3-ATGW-BTGW-41
|
$685.55
|
Call
|
|
|
|
871708
|
871708
EATON MODULE DGMC2-3-ABGW-BAGW-41
|
$685.55
|
Call
|
|
|
