Manual 3 & 6 Port Selector Valves
3 & 6 Port, Rotary Lever Action (open on change over)
|
Model |
Description |
Max. Flow lpm |
Max. Press. bar |
|
DH5/3A |
3 Port, 3/8” BSP |
60 |
315 |
|
DH10/3A |
3 Port, 1/2” BSP |
90 |
315 |
|
DH20/3A |
3 Port, 3/4” BSP |
140 |
315 |
|
DH25/3A |
3 Port, 1” BSP |
200 |
250 |
|
|
|
|
|
|
DH5/4A |
4 Port 3/8” BSP |
60 |
315 |
|
DH10/4A |
4 Port 1/2” BSP |
90 |
315 |
|
DH20/4A |
4 Port 3/4” BSP |
140 |
315 |
|
DH25/4A |
4 Port 1” BSP |
200 |
250 |
|
|
|
|
|
|
DH5/6A |
6 Port, 3/8” BSP |
60 |
315 |
|
DH10/6A |
6 Port, 1/2” BSP |
90 |
315 |
|
DH20/6A |
6 Port, 3/4” BSP |
140 |
315 |
|
DH25/6A |
6 Port, 1” BSP |
200 |
250 |
3 & 6 Port, Push Pull Lever Action (open on change over)
|
Model |
Description |
Max. Flow lpm |
Max. Press. bar |
|
DF5/3A12L |
3 Port, 3/8” BSP, detent |
60 |
315 |
|
DF5/3A17L |
3 Port, 3/8” BSP, spring return |
60 |
315 |
|
DF10/3A12L |
3 Port, 1/2” BSP, detent |
90 |
315 |
|
DF10/3A17L |
3 Port, 1/2” BSP, spring return |
90 |
315 |
|
DF20/3A12L |
3 Port, 3/4” BSP, detent |
140 |
315 |
|
DF20/3A17L |
3 Port, 3/4” BSP, spring return |
140 |
315 |
|
|
|
|
|
|
DF5/6A12L |
6 Port, 3/8” BSP, detent |
60 |
315 |
|
DF5/6A17L |
6 Port, 3/8” BSP, spring return |
60 |
315 |
|
DF10/6A12L |
6 Port, 1/2” BSP, detent |
90 |
315 |
|
DF10/6A17L |
6 Port, 1/2” BSP, spring return |
90 |
315 |
|
DF20/6A12L |
6 Port, 3/4” BSP, detent |
140 |
315 |
|
DF20/6A17L |
6 Port, 3/4” BSP, spring return |
140 |
315 |
Downloads
| Code | Product Name | Price | Stock Availability | Quantity | Enquire |
|---|---|---|---|---|---|
|
5V12105000
|
5V12105000
WALVOIL 12/S5 KIT TWO POSITION DETENT POSN. 1 & 2 DF5
|
$63.71
|
In Stock
|
|
|
|
5V12110000
|
5V12110000
WALVOIL 12/S5 KIT TWO POSITION DETENT POSN. 1 & 2 DF10
|
$90.80
|
In Stock
|
|
|
|
5V12120000
|
5V12120000
WALVOIL 12/S5 KIT TWO POSITION DETENT POSN. 1 & 2 DF20
|
$128.75
|
Call
|
|
|
|
122050023
|
122050023
WALVOIL DFC050/3B17GSLP DIVERTER
|
$323.88
|
In Stock
|
|
|
|
122052040
|
122052040
WALVOIL DF5/3A12L DIVERTER SPOOL TYPE 3/8
|
$403.77
|
Call
|
|
|
|
122054040
|
122054040
WALVOIL DF5/3A17L DIVERTER SPOOL TYPE 3/8
|
$345.51
|
In Stock
|
|
|
|
122082040
|
122082040
WALVOIL DF5/6A12L DIVERTER SPOOL TYPE 3/8
|
$476.98
|
Call
|
|
|
|
122084040
|
122084040
WALVOIL DF5/6A17L DIVERTER SPOOL TYPE 3/8
|
$476.98
|
Call
|
|
|
|
124052040
|
124052040
WALVOIL DF10/3A12L DIVERTER SPOOL TYPE 1/2
|
$449.85
|
Call
|
|
|
|
124054040
|
124054040
WALVOIL DF10/3A17L DIVERTER SPOOL TYPE 1/2
|
$528.42
|
In Stock
|
|
|
|
124082040
|
124082040
WALVOIL DF10/6A12L DIVERTER SPOOL TYPE 1/2
|
$523.02
|
Call
|
|
|
|
124084040
|
124084040
WALVOIL DF10/6A17L DIVERTER SPOOL TYPE 1/2
|
$615.24
|
Call
|
|
|
|
126052040
|
126052040
WALVOIL DF20/3A12L DIVERTER SPOOL TYPE 3/4
|
$639.59
|
Call
|
|
|
|
126054040
|
126054040
WALVOIL DF20/3A17L DIVERTER SPOOL TYPE 3/4
|
$639.59
|
Call
|
|
|
|
126082040
|
126082040
WALVOIL DF20/6A12L DIVERTER SPOOL TYPE 3/4
|
$742.51
|
Call
|
|
|
|
126084040
|
126084040
WALVOIL DF20/6A17L DIVERTER SPOOL TYPE 3/4
|
$872.56
|
Call
|
|
|
|
132031110
|
132031110
WALVOIL DH5/3A DIVERTER ROTARY TYPE 3/8
|
$188.32
|
Call
|
|
|
|
132061110
|
132061110
WALVOIL DH5/6A DIVERTER ROTARY TYPE 3/8
|
$397.05
|
Call
|
|
|
|
134031110
|
134031110
WALVOIL DH10/3A DIVERTER ROTARY TYPE 1/2
|
$209.99
|
Call
|
|
|
|
134061110
|
134061110
WALVOIL DH10/6A DIVERTER ROTARY TYPE 1/2
|
$460.72
|
Call
|
|
|
|
136031110
|
136031110
WALVOIL DH20/3A DIVERTER ROTARY TYPE 3/4
|
$273.71
|
Call
|
|
|
|
136061110
|
136061110
WALVOIL DH20/6A DIVERTER ROTARY TYPE 3/4
|
$608.46
|
Call
|
|
|
|
137031110
|
137031110
WALVOIL DH25/3A DIVERTER ROTARY TYPE 1
|
$384.76
|
Call
|
|
|
|
137061110
|
137061110
WALVOIL DH25/6A DIVERTER ROTARY TYPE 1
|
$829.27
|
Call
|
|
|
|
170011012
|
170011012
WALVOIL HANDLE DF5 M8 x 120MM
|
$12.12
|
Call
|
|
|
|
170011015
|
170011015
WALVOIL HANDLE DF5 M8 x 150MM
|
$12.12
|
Call
|
|
|
|
170012020
|
170012020
WALVOIL HANDLE DF10 200MM
|
$12.12
|
Call
|
|
|
|
170013020
|
170013020
WALVOIL HANDLE DF20 200MM
|
$17.58
|
Call
|
|
|
|
D3V-3/8
|
D3V-3/8
GALTECH SELECTOR VALVE 3/8" 3 PORT
|
$163.47
|
In Stock
|
|
|
|
D4V-1/2
|
D4V-1/2
GALTECH SELECTOR VALVE 1/2" 4 PORT
|
$153.65
|
Call
|
|
|
|
D4V-3/4
|
D4V-3/4
GALTECH SELECTOR VALVE 3/4" 4 PORT
|
$222.66
|
Call
|
|
|
|
D4V-3/8
|
D4V-3/8
GALTECH SELECTOR VALVE 3/8" 4 PORT
|
$138.14
|
Call
|
|
|
|
D6V-3/8
|
D6V-3/8
GALTECH SELECTOR VALVE 3/8" 6 PORT
|
$333.93
|
In Stock
|
|
|
